TRANSAL

Protection relays and controllers

DEIF's protection relays and controllers, types TRANSAL DC-2TF, ACV-3TF, ACI-3TF, PFC-2TF, DC-2TB, AVC- 3TB, ACI-3TB and PFC-2TB, has been phased out and is no longer for sale.

Contact us

End of life

NO LONGER FOR SALE

DEIF’s protection relays and controllers, types TRANSAL DC-2TF, ACV-3TF, ACI-3TF, PFC-2TF, DC-2TB, AVC- 3TB, ACI-3TB and PFC-2TB, has been phased out and is no longer for sale.

This page provides technical documentation only.

If you have any questions, please contact DEIF at +45 9614 9614.

Read more

Documentation

Generator protection unit

Generator protection unit GPU-3

PLC
Engine and Generator protection
Engine CANbus
Rear mount
Din rail mount
RS485

Power relay

Power relay RMP-121D

Generator and prime mover protection
ANSI code 32
3-phase measurement
LED indication of alarm condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mountin

Power relay

Power relay RMP-112D

Generator and prime mover protection
ANSI code 32
3-phase measurement
LED indication of alarm condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Power relay

Power relay RMP-111D

Generator and prime mover protection
ANSI code 32
3-phase measurement
LED indication of alarm condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Current relay

Current relay RMC-142D

Earth fault protection at two levels
Built-in filter for 3rd harmonic
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mountin

Current relay

Current relay RMC-132D

Double over-current relay (I> + I>)
ANSI code 50 and 51
Measurement of 3-phase currents
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Current relay

Current relay RMC-131D

Differential current relay
ANSI code 87
Measurement of 3-phase currents
Non-stabilised measurement
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
Extra change-over relay contact for signalling
35 mm DIN rail or base mounting

Current relay

Current relay RMC-122D

Short circuit and over-current
I>>: 100 to 400 %, I>: 50 to 150 %
Combined functionality
Short circuit relay (I>>)
ANSI code 50 and 51
Measurement of 3-phase currents
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Current relay

Current relay RMC-121D

Short circuit and over-current circuit relay (I> + I>>)
ANSI code 50 and 51
Measurement of 3-phase currents
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Current relay

Current relay RMC-111D

Short circuit relay (I>>)
ANSI code 50 and 51
Measurement of 3-phase currents
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mountin

Voltage relay

Voltage relay RMV-142D

Under- and Over-voltage.
U>: 100 to 120 %, U<: 80 to 100 %.
Single phase measurement.
Under-voltage/over-voltage (U< + U>)
ANSI code 27 and 59
3-phase measurement
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Voltage relay

Voltage relay RMV-132D

Under-voltage (double).
U<: 80 to 100 %, U<: 80 to 100 %.
Under-voltage/over-voltage (U< + U>)
ANSI code 27 and 59
3-phase measurement
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Voltage relay

Voltage relay RMV-122D

Over-voltage (double).
U>: 100 to 120 %,U>: 100 to 120 %.
Under-voltage/over-voltage (U< + U>)
ANSI code 27 and 59
3-phase measurement
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting

Voltage relay

Voltage relay RMV-112D

Under- and over-voltage.
U>: 100 to 120 %, U<: 80 to 100 %.
Under-voltage/over-voltage (U< + U>)
ANSI code 27 and 59
3-phase measurement
LED indication of fault condition
Timer-controlled tripping
LED indication for activated relay
35 mm DIN rail or base mounting
